This wall-mounted trivet holder keeps hot pads off the countertop using two compact brackets installed side by side. It’s discreet, space-saving, and installs with strong double-sided tape, no drilling required. A printable alignment template is included for the standard setup based on a Ø180 mm trivet with a 25 mm useful storage gap. If you use different trivet diameters or need another storage gap, please leave a comment/request and I will provide an adapted file and template.

📏 Dimensions line Length/Width/Height: 65/38/53 mm — 2.56/1.50/2.09 in. (per bracket) Useful storage gap: 25 mm — 0.98 in. Reference trivet diameter: 180 mm — 7.09 in.

🧪 Printing & Assembly Tips Nozzle: 0.4 mm Layer height: adaptive (e.g., 0.16–0.24 mm for fine exterior) Infill: 15% (grid or gyroid) Perimeters & shells: 3–4 walls; 4–5 top/bottom layers Supports: none Orientation: flat base on the build plate Material: PLA recommended (cost-effective, lower impact); keep away from heat/steam sources Print set: 2 × brackets + 1 × alignment template (for Ø180 mm standard) Installation (tape-mount): clean wall with isopropyl alcohol, apply a high-bond tape (e.g., 3M VHB) covering the full back surface, use the template to place brackets, press firmly 30–60 s, and allow adhesive to cure (ideally 24 h) before loading Custom spacing: for other trivet sizes or a different storage gap, contact me for a tailored file and template; the stock model does not adjust on its own Load note: adhesive performance depends on tape quality and surface prep; increasing capacity beyond 25 mm may exceed safe limits for tape-only mounts
