This model is a replica (with some adaptations) of the famous DUM-series pit droid from Star Wars. The model is articulated and can be positioned in different poses. The only parts who may require glue are the antennas and the whole model can be printed on a Prusa Mini.  The model  is 60cm tall and to build it you will need the following extra parts:
NUTS:
-24x M4 self-locking nuts
-1x M5 self-locking nut
SCREWS (cylindrical head if not specified):
-6x M4 10mm
-2x M4 12mm
-2x M4 14mm
-2x M4 15mm flat head
-1x M4 16mm
-4x M4 22mm
-2x M4 25mm
-1x M4 30mm
THREADED BARS:
-1X 56mm
-1X 88mm

PIT DROID scale 1:2

WAC DROID_head.stl

The model is split in to several pieces to fit on to a printer with a build volume of 25 x 21 x 21 cm or 9,84 x 8,3 x 8,3 in. (Example Prusa MK3)
All parts are rotated for optimal printing with minimal supports.
Besides the printed parts you only need some filament strips and 6 mm black electric wire (for the side wire detail).
You can see more details in my build video:
[YouTube](https://www.youtube.com/watch?v=jT_OLkHsA_w)

The model is split so you can print all parts in the right color and then assemble it.

Edit 24.04.2022:

Use 3-4 perimeters for the black rods and go really low infill and max 2 perimeters for all the parts above the head, otherwise it will be too heavy.
If your parts end up to heavy check out this remix by JPMakesStuff: [Link](https://www.printables.com/model/177328-star-wars-d-o-droid-head-support-block)
