**Create a Multicolor Puzzle with a Single-Color Printer!**
By using 5x2mm magnets, adhesive, and this puzzle data, you can create a colorful puzzle without the need for supports (we recommend adding a brim). By printing the color-coded parts with different filament colors, you can achieve a stunning multicolor effect.

**There is an explanation on how to glue magnets. https://youtu.be/DR4dDgUL4IQ**

The puzzle fun begins with attaching neodymium magnets to each piece. Once completed, challenge your family and friends to solve it! After the fun, it makes a perfect decorative piece for your room.
If you prefer, you can also glue the pieces together directly without magnets to enjoy it as a figurine.

As a bonus, we have also included a model with the puzzle pieces fused together.

**Excited! Enjoy a larger puzzle by enlarging it!**
By enlarging the print to 155%, you can create a big puzzle using 8x3mm magnets! The larger size makes it easier for small children to play with and provides great satisfaction.
For more details, please watch this video: https://youtu.be/y-1LrwWMlUI

**Things to prepare**
**(1)** super glue.

**(2)** 44 pieces of 5x2mm magnets.
Magnets can be purchased on Amazon or AliExpress. I bought mine from here: https://s.click.aliexpress.com/e/_ooTqNVy
Alternatively, you can also purchase them from Bambu Lab with the model number CA-003: https://store.bambulab.com/products/round-magnet

When printing at 155%, please prepare 8x3mm magnets.

**How to make**
**(1)** Please print the following files: "Koi_Puzzle_Black_color.stl","Koi_Puzzle_Red_color.stl","Koi_Puzzle_white_color.stl"I recommend adding a brim. No support is needed.

You can enjoy the combination of colors by printing in multiple colors. The print data is set to the optimal orientation, so please print as is. Individual piece data is also included, and you can print only your favorite parts by comparing it with the file name in the image.

**(2)** Glue the magnets into the hexagonal holes. (The hole is made hexagonal to prevent the glue from overflowing.) Be careful with the orientation of the magnets, the holes are designed to be loose, so be sure to glue them firmly.

**(3)** Have fun!


Low Poly Koi Magnet Puzzle (No supports, no AMS)

Koi_Puzzle_white_color.stl

3D MODEL DESCRIPTION
Highly flexible, super cute and supper easy to print - 100% print in place.

Comes with bambulab painted version and stl.

Easy to scale in size.

3D PRINTING SETTINGS
Standard Bambu settings -

No brim required unless you have bad plate adhesion.

Model can be scaled - shown here is at 80% and works perfectly.

If scaled down - no general supports needed, but in your slicer, add tree supports, make sure remove small overhangs is not enabled and enable support critical regions only.

Printed with 2x 0.42mm walls and standard speed.

Gyroid infill recommended.

And that's it, have fun

SUPER CUTE FLEXI STRINGRAY

FLEXI STRINGRAY FULL SIZE.stl

Brighten your space with this captivating dolphin lightbox, featuring customizable text in Fusion 360. Print it with or without the base to suit your needs. Ideal for marine life enthusiasts, this design adds a playful and personalized touch to any room. Easy to print and assemble, it's a unique addition to your decor.

How to change Name:
https://www.youtube.com/watch?v=MC7ybI3dqj4

If you don't have or don't want to install LED's you can just glue the parts together and have an awesome sign!

WARNING!

- remove purge line at the beginning of the print, it may interfere, specially with bigger prints!






Materials and tools:
- glue gun
- aluminum tape
- led strip: simple 1m or 2m white or rgb led USB (recommended 60 LED per meter)
- soldering iron (optional)



RECOMMENDATIONS

- use a textured PEI sheet
- remove purge line at the beginning of the print!
- use the print profile, it has quite a few setting changes that help achieve the best results
- make a hole for the USB strip wherever you like it best with a soldering iron, drill or in the slicer

- use the aluminum tape on the inside of the backplate to help with light diffusion
- glue the LED's the further away from the colored design possible; placing them too close ruins the diffusion and the individual LED's become visible

Bambu Studio Settings:
I always recommend using the print profile I provided since it has settings with which I've been able to get the best results.
If you choose not to here are the main slicer settings I recommend:
- preferences (ctrl + P) → activate developer settings → Quality →Advanced → First Layer Flow Ratio: 1.04 to 1.08
- Quality → Wall generator → Arachne
- Quality → Wall transitioning threshold angle → 30º to 50º
- Strength → Advanced → Infill/wall overlap → 20% to 25%
- Increasing retraction / reducing temperature can help reducing wisps
- Order color printing from lightest to darkest color


How to make a hole in Bambu Studio:
https://www.youtube.com/watch?v=OsA23WCxRtg&t=14s&ab_channel=braga3dprint




Assembly video:
https://www.youtube.com/watch?v=QNsShLmXYh0&t=8s&ab_channel=braga3dprint




How to print without AMS:
https://www.youtube.com/watch?v=RUSTGxOOS_U&t=4s&ab_channel=braga3dprint
