**Please read below for information about slicer settings and update log!**

A huge thank you to the M3D Aetas Members for the countless hours of printing and feedback to help make this design come together!

Fantastic Vending Machine is a fully 3d printed surprise capsule machine. This design will see continued improvement and enhancement over time with upgrades such as printable capsules, larger capacity and a token system!

At 100% scale it can use 2” capsules and at 80% scale can use 1.5” capsules. I’ll include links of where you can acquire them down below.
I’ve just about finished the assembly video and I’ll be posting that to YouTube later this evening.

I can’t wait to start seeing everyone’s prints and I really hope you all enjoy the design! My 8 and 13 year olds have both staked claims to multiple of the ones I’ve printed as they just like playing with them! 😂

**Print settings for Hopper Front Screen:**

- Wall Loops: 3
- Top Layers: 0
- Bottom Layers: 0
- Infill Pattern: Honeycomb
- Infill Density: 3%
- Infill Direction: 30

**Print settings for all other files:**

- Use auto supports on Hopper, Tumbler and Tumbler Handle
- 3 Walls, 15% Gyroid

Surprise Capsules:
- Colored Capsules 2” - [https://amzn.to/4deJmqs](https://amzn.to/4deJmqs)
- Clear Capsules 2” - [https://amzn.to/4jVeqyj](https://amzn.to/4jVeqyj)
- Colored Capsules 1.26” - [https://amzn.to/456i97m](https://amzn.to/456i97m)
- Clear Capsules 1” - [https://amzn.to/42Tcv7i](https://amzn.to/42Tcv7i)

Update 06/28:
- Hopper Plug r2
- Base Bottom r2 (with ramp)
- Add-on Base Bottom Ramp (existing prints)

M3D - Fantastic Vending Machine

Hopper-Front-Screen_standard.stl

FVM-BaseBack_R3.stl

FVM-BaseFront_R3.stl

FVM-BaseFront_r3.stl

FVM-BaseSides_R3.stl

FVM-Hopper-Frame_flush_standard.stl

FVM-Hopper-Plug_R2.stl

FVM-Hopper.stl

FVM-Tumbler-Handle.stl

FVM-Tumbler-Nubs_R3.stl

FVM-Tumbler-Plug_R2.stl

FVM-Tumbler-Rings.stl

FVM-Tumbler.stl

FVM_Base_Bottom_R2.stl

FVM-Hopper-Lid-Bezel.stl

Hopper-Screen_honeycomb.stl

This box was born as a special collaboration between me and [3D Printing World](https://thangs.com/designer/3dprintingworld), where I sculpted the Magnolia flower on top and he designed the mechanical box.

This box is an outcome of a special request for a marriage proposal of a great member of the 3D Printing Community.
**Caleb**, the producer and costar of [HotMakes](https://youtube.com/@HotMakesLive?si=8Z-TZeVbEQwuodcW) wanted a mechanical ring box that somehow incorporates his girlfriend (now fiancés) favorite flower, the magnolia.
- - -
This type of mechanism **3D Printing World** created is perfect for a magnolia since the number of petals on the flower line up perfectly with 60 degrees.
Each of the six petals on top are connected to an outside ring gear and an inside torsion loaded spring gear.
When you hold the box and rotate the ring gear the pedals open. When you let go of the gear, the spring loaded gear forces the pedals to come together.

_**The bottom of the box prints in place.**
Use a .4mm nozzle and .2mm layer heights or smaller. You will need to print three double pedals and three single pedals. You will also want to print the shim which will help to glue the pedals squarely onto the shafts. None of the parts require supports. **There is also 3MF files for dual color pedals.**_

_The top petals glue onto locators on the top of each shaft to glue it together.
Make sure you alternate between single and double pedals.
**See the assembly video for assembly instructions.**_
- - -
Much thanks to **3D Printing World** for creating this brilliant and magical mechanism that makes the box so unique, without which the magic would not have been possible.
You can also download these files from **3D Printing World**. Please support him [here](https://than.gs/u/35786?plans=true)
- - -

**If you have any questions or inquieries about the files, if you have any suggestions and requests, or anything else, please don't hesitate to let me know!**

- - -

Please don't be shy and upload your make!

(_If you share it on your socials, please be sure to tag : @randomizy.3d [FB / IG] ; @randomizy3d [Twitter / Tik Tok] so that I can see it!_)

- - -
**Check out the amazing 3D Printing World profile here**: https://than.gs/u/35786
- - -

**INSTAGRAM:** https://www.instagram.com/randomizy.3d/

**TWITTER:** https://twitter.com/Randomizy3D

**FACEBOOK:** https://www.facebook.com/randomizy.3D

**Check More Here:** https://linktr.ee/Randomizy

- - -
_If you like my work and would like to support me so that I can bring you new content, receive exclusive benefits and you're interested in having a commercial license for selling 3D Printed items (not files) of my works, please do consider joining my Membership here:_ https://than.gs/u/296962?plans=true

Magnolia Box

TOP-2.stl

Magnolia Box (3 colors) (2 plates).3mf
