wrist plate 3d model
wrist plate 3d model

wrist plate

This is the assembly that holds the project to the limb of your choice. It was designed to be adjustable and modular for easy arrangement of the components needed for your gripping needs. The plate is TPU prints upside down, so the grooves will be on top on the build plate, but facing the limb during use. The through holes are modeled to comfortably hold the head of an m3 screw without digging into skin. The clips are printed in PLA with supports on the build plate only, and bolt together with a recessed hex nut to hold an elastic strap firm. Adjustment is a bit cumbersome, but the straps wont work loose during wear.
