Mount for 2 Nimbles V1 on a Cyclops/Chimera+ Aqua

2 downloads · 5 years ago · Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:2824309. Use this to

This model is restricted by licensing terms.

View license.

Description

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:2824309.

Use this to mount 2 Nimbles on a Chimera+ Aqua or a Cyclops+ Aqua. Not that this is only the mount to be able to bolt 2 Nimbles on top. There is no mount for a type of printer yet. That is the main reason it is still WiP.

You can use this as the basis for your own design or if you have a specific printer you want to mount it on, let us know and we will help.

Edit: Added much-needed holes for the Nimble mounting screws. They got lost in translation.

The STL models are checked and optimised. The parts that need a different orientation to print properly are rotated to the preferred printing position.

The Nimble Extruder

With an installed weight of less than 27 grams on your carriage/effector the Zesty Nimble is the smallest and lightest extruder you can buy, it has ample torque and can be mounted in multiple orientations.

The Nimble is available from Zesty Technology.
