Subaru Crosstrek Visor Pivot 2019+

Replacement visor pivot for a 2019 Crosstrek, and applicable to other models. The unique two-piece design permits the large power connector to pass through.

To assemble: Slide together side 1 and side 2 so the shaft of the visor is in between the two pieces. Slide collar over shaft so it lines up with the bevels of the sides. Secure with a dab of super glue if you like. Screw in as assembly to ceiling.

Recommended print settings: Material: ASA or PA6 Walls: 10 Infill Percentage: 100%

OnShape CAD Link
