Spool.stl

by

vinito

Follow
Follow
Like
Spool.stl by vinito full viewable 3d model
Loading preview...
0 Likes2 DownloadsJuly 15, 2021


Community Uploads

No photos added yet, be the first to upload a photo!


0 Likes2 DownloadsJuly 15, 2021

Community Uploads

No photos added yet, be the first to upload a photo!

There is a nut for this on my designs page Designed to work with the filament rack that comes with Palette 2 (10mm rod) but works just as well separately and generally. When used with the Palette-supplied rack, four fits easily. You can skip the bearings and it spins easily on a rod (12mm diameter or less) OR You can slip some 10mm ID x 15mm OD x 4mm Width bearings (such as 6700, 6700zz etc.) if you prefer The only support you might need is inside the step where the bearing will go, but might not need it. The ones I printed came off the printer and threaded together perfectly with zero cleanup and my printer is nothing special.
CategoryHobbies & Games
