Pinewood Derby Cutting Jig

by
spirilis
Follow
Follow
Remix Model
spirilis
spirilis
Image 1 of 4
Pinewood Derby Cutting Jig 3d model
2D
3D
Makes
Pinewood Derby Cutting Jig 3d model
Pinewood Derby Cutting Jig 3d model
Pinewood Derby Cutting Jig 3d model
Pinewood Derby Cutting Jig 3d model
This model is restricted by licensing terms.
0 Likes1 DownloadsJanuary 25, 2024
This model is restricted by licensing terms.


If you don't have a band saw, use this 3D printed guide with a bow saw to cut your Pinewood Derby car to a cool ~10mm thick.

Four screw holes on the outer perimeter (1/4" or 7mm) are used to secure the jig to a piece of plywood (or similar). The pinewood derby car slips inside, axle slots should be on the same side as the bow saw cutting guide (resulting in a ~10mm thick car). After cutting, unscrew the jig, flip it over and use a screwdriver to push through the 2 holes on the bottom (back & forth) to wiggle the car out of the jig.
