Cable P Clip for 20mm Conduit

by

peaberry

Follow
Follow
Like
Cable P Clip for 20mm Conduit by peaberry full viewable 3d model
Loading preview...
1 Likes8 DownloadsJanuary 24, 2022

This model is restricted by licensing terms.

Community Uploads

No photos added yet, be the first to upload a photo!

This model is restricted by licensing terms.

1 Likes8 DownloadsJanuary 24, 2022

Community Uploads

No photos added yet, be the first to upload a photo!

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:2471085. This is a P Clip for 20mm Conduit. It's designed to suit corrugated 20mm conduit (which actually seems to be about 21mm outside diameter), but should be suitable for rigid PVC tubing also. The internal diameter when printed is 22mm, which clamps down to 21mm when the screw is tightened. It needs one countersunk screw for mounting (it would suit a 6g x 5/8" wood screw for example). I printed this in PLA, and found it was flexible enough to push onto the conduit.
