skadis t-clip ifixit IF145-307-4 magnet bracket

This is a bracket for the Ikea SKÅDIS pegboard to hold an iFixit Pro Tech Toolkit. It uses 4x 10mm (diameter) x 3mm (thick) magnets to hold the kit. This requires the version of the screwdriver kit with the metal back.

The bracket is held tightly on the SKÅDIS pegboard using the Skadis T-Clip System by Line Arc Line: https://www.printables.com/model/256896-skadis-t-clip-system

This bracket is inspired by Ifixit Kit For Ikea Skadis by VolumetricSolutions. It is not a remix, I remade it from scratch to use the T-Clip system and different magnets. https://makerworld.com/en/models/240068?from=search#profileId-255989

Note: The magnet sockets on the bottom of the bracket are optional.

Edit on Onshape: https://cad.onshape.com/documents/da881449d46d23951a97b775/w/bdb2d4bd12aee973fbe7ba69/e/e7c996fba280ca40c803a3e8


0 Likes0 DownloadsDecember 27, 2024

Instructions

Filament • 0.2mm

MaterialPLA
Layer height0.2 mm
Infill density15 %
SupportsNone
BrimNo
