Gridfinity Baseplate with Clips and Rubber Feet
27 downloads · 2 years ago · This is a 1u tall version of my [tunnel baseplate](https://than.gs/m/859253); at this height, the X/
This is a 1u tall version of my tunnel baseplate; at this height, the X/Y tunnels go away, leaving just Z oriented 3u (21mm) rounded holes.
Baseplate sections are joinable with rabbit clips, and have pockets on the bottom for stick-on rubber feet (defaults designed for 6x2mm rubber feet).
Slicing guidance:
- import an STL into your slicer
- split the clip object from the baseplate
- slice the clip with no top/bottom layers, no infill, and 2-3 walls ; they should be only wall paths
- duplicate the clip as many times as desired
Parameterized openscad model for easy customization: https://github.com/jcorbin/gridfinity-risers
