Gridfinity Angled Arduino Board Mount (Ports Left) - Remix

Reasons For This Remix: As of this post, the source Arduino board mount (1) has a Gridfinity-fitting base, but the magnet cavities are sized for much larger diameter magnets (2) source model is y-mirrored such that the direct print results in an Arduino board only fitting onto the pegs with the board pins facing into the mount, inaccessible (3) even printing after mirror correction, if the mount is placed on a Gridfinity baseplate behind but adjacent to a Gridfinity breadboard holder, the lower set of Arduino pins sit too low to be conveniently accessed

.

What Was Done: I took the base of a ZackFreedman 2x1 gridfinity divider bin, added a riser, and then stacked a y-mirrored version of the source Arduino board mount (minus the large-magnet Gridfinity feet base) onto the riser.

.

Source Arduino Board Mount: https://thangs.com/designer/thatguysquig/3d-model/60%C2%B0%20Uno%20Stand%20For%20Gridfinity%20%28ports%20on%20Left%29v2.stl-657099
