3D CAD Model Description for Fiskars Pro CarbonMax Snap-Off Utility Blade Sleeve

Overview: A functional and compact 3D printable sleeve designed to securely hold Fiskars Pro CarbonMax 18mm Snap-Off Utility Blades. This innovative blade sleeve is tailored to complement the blade’s design, providing a safe and reliable way to store and organize blades with a snap-together, glue-free assembly.

Key Features: Blade-Specific Design:

• Specifically crafted for Fiskars Pro CarbonMax 25mm Snap-Off Utility Blades, which are recognized for their sharpness and durability.
• The sleeve interior mirrors the blade’s dimensions, featuring custom slots and contours for a secure and snug fit.

Two-Part Snap-Fit Mechanism:

• Bottom Piece: Precisely machined to cradle the 25mm snap-off blade, ensuring stability and edge protection. Features cutouts to align with the blade’s segmentation for easy handling.
• Top Piece: A protective cover that slides over the bottom, locking into place with interlocking tabs and grooves for secure closure.

Ergonomic and Compact Design:

• Smooth exterior edges for user safety and comfortable handling.
• Compact size designed for easy portability and storage in toolboxes or pockets.

Enhanced Durability:

• Designed for 3D printing with high-strength materials such as PLA, ABS, or PETG for impact resistance and longevity.
• Matches the rugged durability of the CarbonMax blades, which are engineered to remain sharp up to 24 times longer than standard utility blades.

Customizable Features:

• Space for embossed or engraved labels for easy identification.

• Slight tolerances for easy scaling to fit other similar blade models.

Additional Specifications Based on Image Reference: Blade Support Ridges: The sleeve’s inner surface features notches and ridges matching the snap-off blade design, ensuring secure holding without excessive movement. Edge Clearance: A recessed portion allows safe access to the blade while maintaining its cutting edge protection. Blade Fitment Slots: Each slot aligns with the blade’s snap-off points, adding stability and alignment during storage.

File Details: File Format: STL or STEP Recommended Print Settings: Layer Height: 0.2 millimeters Infill Density: 30 percent for strength Support Needed: Use organic for the small tabs Print Orientation: large flat sides optimal strength and fitment

This CAD model, inspired by the Fiskars Pro CarbonMax blade’s precise geometry, ensures your blades are stored safely, extending their lifespan while offering convenience and reliability.
