F2000 M-Trigger Classic

Subscribe for access starting at $20 USD
Get access to this model and 14+ more

✅ Professionally designed, high quality, and guaranteed fitment ✅ STEP files included for direct editing in CAD software ✅ 3MF print files included (Bambu Studio / Orca Slicer + Bambu PAHT) ➕ Members get 20% off all Fiber Nylon 3D printing at srairsoft.com

The F2000 M-Trigger Classic is a drop-in microswitch trigger system designed by Shadow Regime Airsoft. Upgrade your F2000 with better trigger response, shorter trigger travel, and a mosfet of your choice.

More info on our website.

We use Bambu PAHT-CF to print ours. Most PA-CF or PA-GF should also work. These parts are small and will see moderate forces and vibrations. We've found carbon fiber nylons to be the best mix of stiffness and durability. Print with weaker materials at your own risk.

Required hardware:

  • Hardware kits are available on our website
  • 3x20mm extension spring
  • 3x10mm extension spring
  • Non-ETU F2000's can reuse both trigger springs from inside the original trigger unit
  • (2) M2 heat set threaded inserts
  • (2) M2x8 screws
  • (4) M2 oversized washers (example)
  • Standard sized 20x10x6mm ish SPDT lever microswitch
  • A hardwired mosfet. Compatible: Perun AB++, Gate X-ASR, NanoASR, NanoHard, MERF, Warfet.
