Rotary Tool Leather Sanding Rig with Vacuum Attachment - HD Version

A permanent mount version of this design can be found here: https://thangs.com/designer/motolupo2022/3d-model/Rotary%20Tool%20Permanent%20Table%20Mount%20-%20Bolt-in%20%26%20Screw-in%20Models-1239863

This is a HD version of this design that I use for sanding leather edges:

https://thangs.com/mythangs/file/1154566

I made this model with a single piece collar and widened 1mm and 2m depth grind plates for precision work. As seen in the photos, I cut and glued a piece of leather on the inside mating surface so the outer surface of the leather won't be scratched as it runs across the sanding drum. This way I am able to get fast, level sanded edges and not scar up finished pieces. The port at the bottom is for attaching a vacuum cleaner hose, and it can be remixed to suit your needs. Note the size of the drum used in the photo, you will need to remix the grind plate if you use a different diameter drum.

Print with PLA+, CF-PLA etc. as long as you use a properly dried, rigid filament and it will be very strong. I use a 50% triangular infill.

I use it with this design I made for a rotary tool table mount:

https://thangs.com/designer/motolupo2022/3d-model/Rotary%20Tool%20Table%20Mount%20-%20Reinforced-1160736

The standard - light duty - version can be found here:

https://thangs.com/designer/motolupo2022/3d-model/Rotary%20Tool%20Table%20Mount-1153716

Dry your filament, eat your vegetables, don't do drugs.
