Ghostbusters Afterlife - Proton Pack Power Switch

by

Bunjimun

Follow
Follow
Remix Model
Like
Ghostbusters Afterlife - Proton Pack Power Switch by Bunjimun full viewable 3d model
Loading preview...
8 Likes80 DownloadsNovember 24, 2021


Community Uploads

Ghostbusters Afterlife - Proton Pack Power SwitchGhostbusters Afterlife - Proton Pack Power Switch


8 Likes80 DownloadsNovember 24, 2021

Community Uploads

Ghostbusters Afterlife - Proton Pack Power SwitchGhostbusters Afterlife - Proton Pack Power Switch

READ ME

Here’s my take on the afterlife proton pack power switch, it’s based on technical drawings of the Leviton Single Pole 15 amp light switch but uses a super cheap easily available switch (KCD3) -not an ACDC tribute band...

You can take apart the original switch by simply inserting 2 thin shims (plectrums, playing cards, butter knife) on either side to release the tabs or a Stanley knife either side to cut tabs off, then all you need is the metal parts and the housing.

There are 2 versions of the lever depending on what the internals of your switch look like, one type will have a spring with a cap on, this is the spring pin file you will need to trim the spring to fit, the other version is for the type with a spring and a foot type connector, no modification needed, just put the spring in the hole.

You need a pin of some sort that is 10mm long and 2.5mm – 3mm wide (don’t use anything thinner as the switch might not lock into position)

video of how its put together (without plate but do plate 1st) Youtube vid - https://youtu.be/MI6KYhMAyiw

Here are links to buy the switch (note: UK LINKS and there may be cheaper ones on these sites and others, links just to illustrate availability) just search KCD3 and go for the 2 pole on/off version (3 pin also fine)

Amazon - https://www.amazon.co.uk/Rectangle-Long-Rocker-Switch-SPST/dp/B00XWFDNRC/ref=sr_1_4?keywords=On-Off+Long+Rectangle+Rocker+Switch+SPST&qid=1636653251&s=diy&sr=1-4 Ali Express - https://bit.ly/3ojyf6I Ebay - https://www.ebay.co.uk/itm/254768444971

Hope you enjoy - Feedback welcome Ben

ALSO PLEASE DO NOT PRINT AND SELL - ive made these freely available to people who want them, and i offer a painted and assembled version for sale on my Etsy

Etsy Link https://bit.ly/3FINAVE
