Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:6006452.

Hatchetman Ring, printed in black resin and filled with red acrylic paint.

Hatchetman Ring

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:6052001.

Harbor Freight miter saw lever, alot stronger than the thumb press one that broke after a year. A simple tug with a finger and you can change miter degrees.

Harbor Freight miter saw lever

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:6025610.

Battery Cap for Basement Watch Dog emergency batteries, maybe others that i havent found. PETG is very resilient to acid I found after running a few tests.

Battery Cap

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:5895396.

for placing bug foggers in hard to reach places, like the nasty crawl space under your house.Using 3/4" PVC pipe.

Bug Fogger Extender

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:5898667.

Using 4.5mm bearings or BB's and sandwiched between two washers. Great for supporting the weight of the Z axis of a 3D printer taking the weight off the stepper shaft.

Thrust Bearings

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:6019055.

water valve tool for hard to reach places for toilets, sinks, etc. Using 3/4" emt tubing in length you'll need.

Deep reach water valve tool

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:5823490.

This is a super simple fast print, It's a simple open air stand for bluetooth module and amp board. The idea is to use separate speakers and to be used as a mini bookshelf system.

Bluetooth module like: https://www.amazon.com/Bluetooth-Decoder-Decoding-Support-Lossless/dp/B07S51R6V1?crid=2VF8EUX6MGGWI&keywords=bluetooth+module&qid=1675115411&sprefix=bluetooth+module,aps,160&sr=8-49&linkCode=sl1&tag=bbtech0db-20&linkId=90e8eab2bab5908473ed1e9e1adb0684&language=en_US&ref_=as_li_ss_tl

amp board kinda like this: ???

I see Thingiverse still likes to butcher Amazon links so .... https://www.printables.com/model/384811-bluetooth-radio





Bluetooth Radio

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:5634977.

https://github.com/damanbaird/HEXAHEDRON

My way of making a better 3D printer out of the worthless Tronxy X5SA that i had. Hypercube evolution was out of the question since i didnt want to buy all new 3030 extrusion pieces. This build does loose a small amount on the XYZ axis but i think the improvements in the prints was worth it with my glass bed it prints 312x300x340, with some bed support modding it could be as much as 360x310x340 So this... is what i have so far it's running and printing great, but does need some other refinements. Running Klipper firmware. Has magnetic kinetic bed mounts to reduce bed warping while heating. pulleys run on smooth rods not screws! I have included My Amazon affiliate links for the parts i bought.

A few extra parts needed:

designed for the Orbiter 1.5 extruder, since it is what i had at the time.

E3D V6 hotend or clone

2 x 410 10mm smooth rods

2 x 480 8mm smooth rods:

2 x +/- 480mm 2020 extrusion

1 x 500mm 2020 extrusion

6 x 3.5mm x 30mm rods

3 x 10x20 magnets

6 x 20 tooth pulley w/ bearings: https://www.amazon.com/dp/B07JNQQKTC?th=1&linkCode=sl1&tag=bbtech0db-20&linkId=dee3bdfacb5fd327f5e1c2122d723ef6&language=en_US&ref_=as_li_ss_tl

2 x 16tooth smooth pulley w/bearings

2 x LM10UU extra long bearings: https://www.amazon.com/dp/B07JNQQKTC?th=1&linkCode=sl1&tag=bbtech0db-20&linkId=dee3bdfacb5fd327f5e1c2122d723ef6&language=en_US&ref_=as_li_ss_tl

2 x LM8UU extra long bearings: https://www.amazon.com/dp/B07JNQQKTC?th=1&linkCode=sl1&tag=bbtech0db-20&linkId=dee3bdfacb5fd327f5e1c2122d723ef6&language=en_US&ref_=as_li_ss_tl

2 x Hall Effect sensors: https://www.amazon.com/Onyehn-Effect-Magnetic-Sensor-Arduino/dp/B07JMQFY6G?crid=3RHF6S40H1FG2&keywords=ARCEL+Hall+Effect+KY-003&qid=1669171085&sprefix=arceli+5p+hall+effect+ky-003,aps,117&sr=8-2&linkCode=sl1&tag=bbtech0db-20&linkId=6c36f1aa76bf82cc781e35113a6c9c26&language=en_US&ref_=as_li_ss_tl

3 x 10mm magnetic joint balls with M4 threads: https://www.amazon.com/dp/B07HQ72H1R?psc=1&linkCode=sl1&tag=bbtech0db-20&linkId=0b63e18b734adf29b20f550afa2482bf&language=en_US&ref_=as_li_ss_tl

10 feet +/- of 3/4" wire loom

1 x ADXL345 accelerometer

BL Touch or generic

30x10mm round 24volt fan: https://www.amazon.com/gp/product/B08C6Y246L?ie=UTF8&psc=1&linkCode=sl1&tag=bbtech0db-20&linkId=73c2c08c4549ada0703cfaadf410e770&language=en_US&ref_=as_li_ss_tl

T-nuts: https://www.amazon.com/dp/B07HQ72H1R?psc=1&linkCode=sl1&tag=bbtech0db-20&linkId=0b63e18b734adf29b20f550afa2482bf&language=en_US&ref_=as_li_ss_tl


M4x10mm: https://www.amazon.com/dp/B07HQ72H1R?psc=1&linkCode=sl1&tag=bbtech0db-20&linkId=0b63e18b734adf29b20f550afa2482bf&language=en_US&ref_=as_li_ss_tl

5 x 40mm dowel pin: https://www.amazon.com/dp/B07Y4WWBCQ?psc=1&linkCode=sl1&tag=bbtech0db-20&linkId=442eba30a21f02984507510eeb9cc910&language=en_US&ref_=as_li_ss_tl might have to cut or order next size down.

...think i got all that, most other supplies came from the X5SA itself.

If you dont have a Tronxy X5SA and want to start a new you'll need a few extras like …

M3 screws

M4 screws and T-nuts

4 x 2040 extrusions @ 530mm for Z axis

4 x 2020 extrusion @ 560mm for X axis

4 x 2020 extrusion @ 530mm for Y axis

3 x 8mm linear guide rod @ 535mm +/- 5mm

4 x nema 17 stepper motors








HEXAHEDRON

Hexahedron.stl

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:5650103.

Cartoon Bomb uses a piece of 1.75mm filament for the fuse.


Cartoon Bomb

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:5650098.

Engine Cover Retainer Clips for Lexus & Toyota, designed for the cover on my Lexus RX350.

Engine Cover Retainer Clips for Lexus & Toyota

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:5584322.

This install is not for the timid, since it involves cutting your PC case in most cases. Designed to be mounted from the outside of the case through a 43.5mm X 116mm cutout, then attached with sheet metal screws or 1/8 inch (3mm) pop-rivets which i think would look better.

Things needed to install....

Dremel highly recommended
drill and drill bits
PCI-E PCI Express 16X Riser Card Extender like this one:  https://www.amazon.com/EZDIY-FAB-Express-Flexible-Extension-Upgrade/dp/B07MDLYBJ4?pd_rd_i=B07MDLYBJ4&th=1&linkCode=sl1&tag=bbtech0db-20&linkId=612dfe422cdefb42201458bfb9fc53c2&language=en_US&ref_=as_li_ss_tl (affiliated)
pop-rivets ...1/8 inch (3mm) work great.
Total dimensions 58mm X 135mm X 15mm.



Vertical dual pci mount

FirstgenArgontransmissiongasket.stl

102-03    Seal, Oil WBS 30x72x10.stl

USA flag stencil

My sincere thanks for your support!
I plan to churn out more functional prints with a hint of humorous nonsense, these plans keep the printers running so I can improve on my designs. If you would need any help feel free to reach out to me as this plan includes access to my Discord.

King / Queen helper

My sincere thanks for your support!
I plan to churn out more functional prints with a hint of humorous nonsense, these plans keep the printers running so I can improve on my designs.

loyal

8mm_z_rod_mount_X6.stl

A_degree_bed_mount.stl

BL_cooling_fan__4010.stl

BL_cooling_fan_round_fan.stl

B_degree_bed_mount.stl

TR8_mount.stl

V6_mount.stl

XY_joining_X2.stl

XY_joining_caps_X2.stl

carriage.stl

carriage_loom_holder.stl

kinetic_bed_corner.stl

kinetic_bed_mount.stl

kinetic_bed_mount_V2.stl

kinetic_bed_mount_rear.stl

kinetic_rear_bed.stl

lead_screw_bracker_bed.stl

left_motor.stl

left_pulley.stl

rear_bed_mount.stl

rear_printer_loom_holder.stl

right_motor.stl

right_pulley.stl

z_motor_bracket_v2.stl

Model originally uploaded to Thingiverse at https://www.thingiverse.com/thing:5690459.

pronounced: E M T (double) Z

Cartesian 3D printer
This started out in life as one of the BEST and cheapest ways to get a
metal framed Anet A8 3D printer. EMTdubLZ has turned into a complete
DIY custom printer frame with the availability to custimize as you see fit.
Most if not all Anet A8 files on carriages and or the bed from around the
net should be usable. It has been design to be way overkill in the ways on
stability.
2x10' of 3/4" EMT tubing ( you'll have a good length left over for other fun
projects !) 75x #10x3/4 metal self-tapping screws - (https://www.amazon.com/
3cyaun0) a spool of your preferred filament2 Z axis supports that are staggered front to back and left to right
providing a more rigid frame. Takes some measuring to get everything
square but, when done correctly this is a super stiff frame. PSU, display
and motherboard mounts are up to you since there are so many different
varaitions out there now.
Derived from the original EMT8: https://www.thingiverse.com/thing:2818084
Printed parts:
Two of each: frame-corner-v2-fl_rr.stl frame-corner-v2-fr_lr.stl everything
else should need only one.
8mm smooth rod cuts:
2x 436 mm X axis
2x 380 mm Y axis
2x 380 mm Z axis
EMT pipe cuts are as follows:
X: 3x 313mm
Y: 2x 364mm
Z: 4x 443mm
Designed for a build volume of 220x220x240 but can be scaled in either
direction.

EMTdubLZ

emtdublz_upgraded-base-left.stl

emtdublz_upgraded-base-right.stl

fl.stl

fr.stl

frame-corner-v2-fl_rr.stl

frame-corner-v2-fr_lr.stl

heavy-duty-y-mount.stl

heavy-duty-y-tensioner.stl

left_top_rework.stl

parts-cooling-duct.stl

right_top_rework.stl

rl.stl

rr.stl

toothed-idler-tensioner.stl

v6-w_led.stl

x-idler-mount_v2.stl

x-motor-mount.stl

z_level_adjstment_mount.stl

z_level_adjustment_leg.stl

z_stop_foot.stl

The lil piggy bank, print plug file in TPU or simular.

lil Piggy Bank

piggy bank.stl

piggy_bank_plug.stl

I enjoy all kinds of hobbies, electronics, welding, wood working, computers, and... 3D printing. I like being creative and will try to fix almost anything. In other words my designs will mainly be catered to fixing and improving instead of trinkets.
