Spur gears set #1 - Module 2 (11 gears)
667 downloads · 4 years ago · A set of 11 gears with the following characteristics:
Gear module 2mm
- Inner hole 4mm
- Number of
This model is restricted by licensing terms.
View license.
A set of 11 gears with the following characteristics:
Gear module 2mm
- Inner hole 4mm
- Number of teeth variable from 10 to 20
- Thickness 10mm
To correctly couple them, the axis of the couple you consider, shall be placed at a distance given by:
axis_distance [mm] = number_of_teeth_grear_1 + number_of_teeth_gear_2
Note: this formula is valid only for this specific set of gears with module 2.
