Mac Mini M4 Vented Stand (Pairs With Wokyis M5 Dock)

A free 3D-printable base for the Mac mini M4. Two parts, push-fit, no screws, no glue. I built it because I bought a Wokyis M5 retro dock and wanted something underneath that matched the look and kept the M4 breathing.

What's in the print

The stand. A 131.25 x 131.25 mm tray with rounded corners. Walls have a square-perforation grille on three sides for airflow. Inside there's a divider that splits the cavity into intake and exhaust paths so the hot air doesn't recirculate back into the fan. A small empty pocket on one side for future use (no mounts yet, just dead space).

The cover. Sits flush inside the top of the stand. Ø114 mm circular cutout in the middle, lined up to feed the M4's bottom vent ring directly. Rear cutouts route cables out for power, HDMI, Ethernet, and the three USB-C / Thunderbolt ports. Ø10 mm hole at the rear-left for the Mac mini's power button.

Fits

Mac mini M4 / M4 Pro (the 2024 chassis, 127 x 127 x 50.8 mm) Pairs with the Wokyis M5 dock if you have one Won't fit the M1/M2 minis, their port layout doesn't line up with the rear cutout

Print

0.2mm layer height, 3 walls, 15% gyroid infill No supports for the stand. Supports for the cover (the one with the circle in the middle) PLA in cream or ivory. I used Bambu Matte Ivory White

Assembly

Drop the cover into the stand. Drop the Mac mini onto the cover. The round cutout lines up with the bottom vent. Cables exit out the back. If you've got the Wokyis, stack it on top.
