Info This bolt features a thin flat head with a bolt length (from bottom of bolt head to bolt tip) of 14 MM. It matches the Folded Locking Bolt in thread specifications. Which makes it ideal for use in securing the locking brackets to Multiboard Tiles.

This bolt is compatible with the Folded Locking bolt.

Other Sizes At the time of this model releasing, I've also designed and produced the following sizes in the same thread configuration.

• 12 MM
• 12.2 MM Octagon shank
• 14 MM (this bolt)
• 18 MM

Printing Print with the same settings you would use for the Folded Locking Bolt.

Walls: 3 In-Fill: 15% Orientation: Print as provided in the STL

Disclaimer This part was designed from scratch, as such I personally would not classify this as a remix. However, this part is inspired by two Multiboard bolt parts; and due to the nature of the licensing agreement, it is best to consider this a remix. The Folded Locking bolt and the Flat Head bolt. Both Multiboard parts were used as independent references to ensure appropriate & correct fitment for use with the Multiboard ecosystem.

Inspiration Details

• Folded Locking Bolt: Provided correct dimensions for the threading and shaft diameter.
• Flathead Bolt: Provided correct dimensions for the bolt head.

License In addendum to the Multiboard license, while it may be covered to an extent. The following is an additional restriction on top of the Multiboard license.

• You are prohibited from sharing, uploading, posting or otherwise making available to the general public this remix file.

This part is licensed as a remix under the Multiboard license agreement. Download indicates acceptance of the respective license. See https://www.multiboard.io/license for their license information.
