Mihai S

Universal PTFE Tube Jig

by
MihaiDesigns
Follow
Follow
Remix Model
Social
MihaiDesigns
MihaiDesigns
Image 1 of 12
Assembled jig and sample PTFE tubes
Universal PTFE Tube Jig - Assembled jig and sample PTFE tubes - 3d model
2D
3D
Makes
Universal PTFE Tube Jig - Assembled jig and sample PTFE tubes - 3d model
Universal PTFE Tube Jig - Adjustable tube length between 25mm and 55mm long. - 3d model
Universal PTFE Tube Jig - Insert tube, squeeze, and cut. - 3d model
Universal PTFE Tube Jig - Use the chamfer tool to chamfer both ends. - 3d model
Universal PTFE Tube Jig - Insert the tube back, squeeze, then do an inner chamfer with the Philips (+) head or screwdriver - 3d model
Universal PTFE Tube Jig - Chamfered end for the hotend - 3d model
Universal PTFE Tube Jig - Inner chamfer for the extruder side - 3d model
Universal PTFE Tube Jig 3d model
Universal PTFE Tube Jig - One screw and one square nut - 3d model
Universal PTFE Tube Jig - Required tools - 3d model
Universal PTFE Tube Jig 3d model
Universal PTFE Tube Jig 3d model
This model is restricted by licensing terms.
View license.
182 Likes1.3K DownloadsDecember 12, 2021
This model is restricted by licensing terms.
View license.

Makes hotend tubes 25mm to 55mm long.

Print with 0.4mm nozzle and typical settings.

Step-by-step instructions.

BOM:

  • 1 M3 square nut (thick or thin)
  • 1 40mm M3 screw (socket head, fully threaded)
  • Printed parts (typical printing settings)
  • 4mm OD, 2mm or 1.9mm ID (Capricorn XS)

Tools:

  • Cutter
  • Power drill
  • Small Philips (+) screw bit or screwdriver

Pre-supported, pre-oriented, built-in supports.

Check my other projects at mihaidesigns.com.

Categories:

Functional
Other
,
3d Printers
Other

Tags:
