A storage box for your household medical supplies. You can also use it for whatever else, like makeup or screws.

The design comes with a broad variety of inserts to customize it for your personal needs. Single and multi-color printing models are included as STL and 3MF! They work with all current and usual multi color setups.

Instructions

• Select your inserts. The variants A-G all come in different heights from 20 – 140 mm in 10mm steps. The inner height of the box is 140 mm with a little extra clearance. Make sure your selection adds up to that height.
• Print your inserts, the box, the lid and two of the handles and clips.
• Print as many band aids in as many colors as you want for decoration.
• Push the handles into the sides of the box.
• Insert the clips to connect the lid to the box and push them into the cutout with a little force.
• Put the inserts into the box.
• Optional: Add rubber bands to the inside of the lid for extra storage capacity.
• Glue the band aids onto your box.
• Enjoy!

Size assembled: 168 x 237 x 160 mm

Print settings Required build volume: 240 x 240 x 160 mm Material usage: about 700g for a box with three inserts

Material: PLA Print direction: stls are rotated correctly, check images Support: none Nozzle size: 0,4 mm Line width: 0,4 mm Layer height 0,2 mm Infill: 15% Build plate adhesion type: none
